DRT Fabrication Cab Mount Relocation Kit For Tacoma (2005-2023)

Tacoma Cab Mount Relocation Kit – 2005–2023 Toyota Tacoma

The Strongest CMR Kit for 2nd & 3rd Gen Tacomas

The DRT Fabrication Cab Mount Relocation (CMR) Kit is the ultimate solution for running 35” tires on your 2005–2023 Toyota Tacoma. Factory cab mounts don’t provide enough clearance for larger tires, and even with a traditional “cab mount chop,” rubbing issues often remain. Our relocation kit moves the cab mount completely behind the firewall, eliminating interference and allowing proper clearance for 35s.

Built Stronger Than Any Other Kit

• Unlike standard chop or relocation kits, the DRT system is engineered for strength and reliability
• 3/16” frame overlay plate disperses load and prevents stress cracks
• Fully boxed cab mount, the only kit on the market with this level of reinforcement
• Built from laser-cut 3/16” & ¼” plate steel
• .188 DOM tube with Energy Suspension cab mount bushings
• Designed to withstand real off-road abuse without compromise

Why Choose DRT?

If you’re serious about running 35s on your Tacoma, this is the only cab mount relocation kit designed to handle the demands of aggressive off-road driving. Proven by thousands, purpose-built, and engineered for strength—it’s the strongest Tacoma CMR kit on the market.

Vehicle Fitment

• 2005–2023 Toyota Tacoma (2nd & 3rd Gen, 2WD & 4WD)
